DIKAI DK-1500 High Speed Ink Roll Coder with 900 PPM and 60 meters/minute for Automatic Coding at 220V

900 PPM Ink Roll Coder

60 meters/minute Ink Roll Coding Machine

220V High Speed Ink Roll Coder

Luogo di origine:

Shanghai, Cina

Marca:

DIKAI

Certificazione:

CE; ISO 9001

Contattici

Richieda una citazione

DIKAI DK-1500 High Speed Ink Roll Coder with 900 PPM and 60 meters/minute for Automatic Coding at 220V

Dettagli del prodotto

Area di stampa:

Tipo T: ≤13 righe, massimo 20 caratteri per riga; Tipo R: ≤10 righe, massimo 13 caratteri per riga

Tipo dimensioni:

Tipo T: 2.0T, 2.5T, 3.0T, 2.5*7T; Tipo R: 3.5R, 4.5R, 5.5R

Lunghezza del sacchetto:

≥38 mm (stampante 4-up); ≥75 mm (stampante 2-up)

Frequenza di stampa:

≤300 volte/min

Dimensione del rotolo di inchiostro:

36*32 mm, 36*35 mm, 36*40 mm

Voltaggio:

CA220+10 V, 50/60 Hz

Energia:

Fusibile da 140 W, 2 A

Velocità di stampa:

massimo 900 PPM, 60 metri/minuto

Indice della stampa:

Data MFG/EXP, numero di lotto, numero di serie, ecc

Dimensioni:

Unità stampante: 94 mm*100 mm*166 mm

Peso:

Unità di stampa: 4 kg; Scatola del controller: 2 kg

Componenti principali:

Tavola PC

Tipo guidato:

Elettrico

Grado automatico:

Automatico

Velocità massima della stampa:

1200 stampe/minuto

Evidenziare:

900 PPM Ink Roll Coder

60 meters/minute Ink Roll Coding Machine

220V High Speed Ink Roll Coder

Termini di trasporto & di pagamento

Quantità di ordine minimo

Prezzo

$900-1,200

Prodotti correlati

DIKAI DK-1100A Ink Roll Coder with Long Service Life Compact Size and Stable Printing for Date Code and Expiry Date Marking

Ottieni il miglior prezzo

Automatic Hot Ink Roll Coder with 20 Characters per Line and 1 Year Warranty for Expiry Date Printing

Ottieni il miglior prezzo

DIKAI DK-1100B Hot Ink Roll Coder with 1 Year Warranty Long Service Life for Food Industry Date Printing Machine

Ottieni il miglior prezzo

Automatic Hot Ink Roll Coder with AC220+10V Power and 50/60Hz Frequency for Expiry Date and Batch Number Printing

Ottieni il miglior prezzo

Contattici

info@dikaicoding.net

86-21-51086700

Contatto ora

Descrizione di prodotto

DIKAI Dk-1500 Roll to Roll Ink Machine Label Inkjet Hot High Speed Ink Roll Coder

Product Overview

The DK-1500 High Speed Hot Ink Roll Coding Machine, developed by DIKAI's R&D team, is designed for integration with high-speed flow packers. It achieves maximum print speeds of 1200 prints/minute for production dates, lot numbers, expiry dates, and other essential information. Its compact structure, ease of assembly, large printing coverage, flexible formatting options, and minimal printing distance make it ideal for food, daily chemicals, paper, pharmaceutical, and seed industries. The LCD screen enhances controller longevity with minimal maintenance requirements.

Key Features

High-speed printing up to 1200 prints/minute
Compact and durable structure
Large printing coverage area
Simple assembly and operation
Low maintenance requirements
Wide industry applications

Technical Specifications

Product Name	DK-1500 High Speed Hot Ink Roll Coding Machine
Print Area	T-Type (Axial): ≤13 lines, max 20 characters per line R-Type (Radial): ≤10 lines, max 13 characters per line
Type Sizes	T-Type: 2.0T, 2.5T, 3.0T, 2.5*7T R-Type: 3.5R, 4.5R, 5.5R
Pouch Length	≥38mm (4-up printer) ≥75mm (2-up printer)
Print Frequency	≤300 times/min
Ink Roll Required	36×32mm, 36×35mm, 36×40mm
Electricity	AC220+10V, 50/60Hz
Power	140W, 2A fuse
Print Speed	Max 900 PPM, 60 meters/minute
Print Contents	MFG/EXP date, lot number, serial number, etc.

Note: Prices shown are not final. Please consult us for customized solutions.

Packaging & Shipping

The machine is packaged in durable cartons suitable for sea, air, or courier shipping.

After-Sales Service

Comprehensive R&D support
Detailed operation manual guidance
24-hour professional online support
Video tutorial support
Onsite support when required

Frequently Asked Questions

1. Why choose DIKAI?

With 25 years of experience in developing, manufacturing, and selling quality coding machines and consumables, we are committed to meeting diverse customer needs in coding and marking applications.

2. What's the regular lead time for DIKAI products?

Standard lead time is 1-2 weeks after order confirmation. Stocked items ship within 2 working days.

3. What's the warranty for DIKAI products?

Standard warranty is 12 months from date of shipment from our warehouse.

4. How is your after-sales service?

We provide distributor-based support in covered regions, supplemented by online technical services and continuously updated video tutorials.
